Standard top loading washing machines with modern craftsmanship.

Back to Products

These washing machines are simplest form of machines with Stainless Steel cage installed horizontally with the help of two shafts on both sides. The clothes are rotated and tumbled in both directions with the use of Reverse Forward timer to give perfect wash quality. Read Mode

Download
Brochure

Technical Specifications

Model Units PWM-10 PWM-30 PWM-60 PWM-100
Max Capacity    (Dry weight) kg.(lbs) 10 (22) 32 (70) 60 (132) 100 (220)
Basket Diameter mm (in.) 457 (18) 711 (28) 915 (36) 1118(44)
Basket Depth mm (in.) 610 (24) 915 (36) 1067 (42) 1220(48)
Basket Volume cu.m (cu.ft)  0.099(3.53)  0.36(12.82) 0.70 (24.74) 1.2 (42.24)
Door Opening mm (in.) 457(18) x 406(16) 508(20) x 406(16) 660(26) x 460(18) 660(26) x 460(18)
Water Inlet mm (in.) 25(1) 25(1) 50 (2) 50 (2)
Steam Inlet mm (in.) 13 (0.5) 13 (0.5) 13 (0.5) 13 (0.5)
Drain Pipe mm (in.) 50 (2) 75 (3) 100 (4) 100 (4)
Basket Motor Kw (HP) 0.7 (1) 0.7 (1) 2.2 (3) 3.7 (5)
Machine Height mm (in.) 813 (32) 1016 (40) 1220 (48) 1423 (56)
Machine Depth mm (in.) 660 (26) 915 (36) 1118 (44) 1320 (52)
Machine Width mm (in.) 1143 (45) 1676 (66) 1880 (74) 2135 (84)

Standard Features


  • Fabricated with 304/316 Grade stainless steel using argon welding (TIG welding).
  • Precision Temperature controller.
  • Reverse/Forward Auto Timed.
  • Heavy duty fabrication for years of reliable performance.

Optional Features


  • Auto Water level Control
  • Default color is white (can be changed acc. to requirement).
