Aerodynamic clothes dryer for max. energy saving.

Back to Products

A clothes dryer, tumble dryer, or drying machine is used to remove moisture from a load of clothing and other textiles, usually shortly after they are washed in a washing machine. The name Tumble Dryer comes from the Tumble action of Rotating Drum. It uses hot air from Heat Exchanger to reduce moisture and dry the clothes. The Heat Exchanger uses Electricity, Gas or Oil to heat the air. The inner drum Tumble on both sides for faster drying and collects the lint in a lint filter made of steel mesh. The drying time and efficiency of Tumbler depends on its aerodynamic design, CFM and mode of heat source. Perccare make Tumbler Dryers are aerodynamic and its blower design produce more cfm to dry the clothes in a min. possible time. Read More

Download
Brochure

Technical Specifications

Model Units PTM 25 /PTS 25 PTM 50/PTS 50 PTM 70 /PTS 70 PTM100 /PTS100
Max Capacity    (Dry weight) kg. (lbs) 25 (55) 50 (110) 70 (154) 100 (220)
Basket Diameter mm (in.) 965 (38) 1270 (50) 1425 (56) 1550 (61)
Basket Depth mm (in.) 685 (27) 762(30) 915 (36) 1068 (42)
Basket Volume cu.m (cu.ft) 0.50 (17.67) 0.96 (34) 1.4 (50.5) 2 (70.94)
Blower Motor Kw (HP) 1.1 (1.5) 1.5 (2) x 2 1.5 (2) x 2 2.2(3) x 2
Basket Motor Kw (HP) 1.1 (1.5) 1.5 (2) 2.2 (3) 2.2 (3)
Machine Height mm (in.) 1880 (74)  2160 (85) 2260 (89) 2385 (94)
Machine Depth mm (in.) 1220 (48) 1630 (64) 1778(70) 2032 (80)
Machine Width mm (in.) 1120 (44) 1530 (60) 1675(66) 1828 (72)
Air Flow cmm (cfm) >70.8(2500) n.a n.a
Door Opening mm (in.) 560 (22) 685(27) 815(32) 915 (36)
Drying Speed RPM 32 30 28 28
Steam Required per hr. (approx.) Kg (lbs) 40 60 90 120
Electric Heaters for Drying Kw 12 18 24

Standard Features


  • User Adjustable Temp. control for both heaters/steam coils.
  • Reverse/Forward Auto timed.
  • Zero Lint at exhaust with SS micro filtration.
  • Aerodynamic design for fast Humidity reduction.
  • Heavy Duty C channel frame for longer life.
  • Air Chamber insulation for lesser heat loss.
  • Double Blower for more CFM.

Optional Features


  • Steam heating coils or Electric Heaters.
  • HMI with Touch screen controls.
  • Inverter drive for Softer cage movement.
  • Input / Output Humidity check.
  • Phase failure detection.
  • Stainless steel outer covers.
  • Lint filter signal.
  • Air re-circulating sytem.
